SenseCAP S-2108 Soil Moisture, Temperature and EC Sensor
Wireless volumetric water content (vwc), temperature, and pore water EC (pwEC) sensor.
Works with all substrates: rockwool/stonewool, coco coir, peat mixes, organic soils, and mineral soils
Soil electrical conductivity (EC) is a crucial metric that affects plant nutrient availability, soil microbial activity, and crop yield and quality. The sensor accurately measures bulk EC and estimates pore water EC (pwEC) using the Hilhorst method, allowing farmers to make informed decisions about irrigation and fertilization, leading to reduced costs and increased efficiency.
This wireless sensor is specifically optimized for OTA (over the air) configuration with built-in Bluetooth, enabling quick setup and updates. It is also compatible with worldwide LoRaWAN® networks and can cover a long transmission range while keeping lower power consumption. With an ultra-wide transmission range of 2km in urban scenes and 10km in line-of-sight scenes, this sensor is perfect for outdoor use, high UV exposure, heavy rain, dusty conditions, and more.
The sensor is battery-powered, reducing the workload and complexity of deployment. It can be disassembled and installed in a few minutes, making it a hassle-free addition to your farming equipment. With a simple configuration process that can be completed in 4 steps through the SenseCAP Mate APP, you can start collecting data and optimizing your farming practices with ease.
Invest in the SenseCAP S2108 Sensor and revolutionize the way you approach precision agriculture and soil sensing.
- Easy to use: Deploy the sensor in minutes with a few steps. Configure the sensor via bluetooth.
- Wireless: Powered by a replaceable battery, with an expected life up to 10 years.
- Estimates Pore Water Electrical Conductivity: The sensor measures bulk EC and soil permittivity and calculates the pore water EC using the Hilhorst model.
- Low Data Fees: SenseCAP data subscription is a prepaid low flat rate of $11.88 per sensor node, per year.
SenseCAP data subscription is a prepaid low flat rate of $11.88 per sensor node, per year.
| MEC-20 Sensor Specifications | |||
| Output Interface | RS485 MODBUS-RTU | ||
| Power Supply | 3.6-30V/DC | ||
| Power Consumption | 6mA @ 24 VDC | ||
| Soil Moisture Measurement | Range:0-50%,0-100% Resolution:0-50%:0.03%,50-100%:1% Accuracy:0-50%:2%,50-100%:3% | ||
| EC Measurement | Range: 0-5000us/cm, 10000us/cm, 20000us/cm Resolution: 0-10000us/cm, 10us/cm; 100000-20000us/cm, 50us/cm Accuracy: 0-10000us/cm, ±3%; 10000-20000us/cm, ±5% EC temperature compensation: 0-50 Celsius | ||
| Temperature Measurement | Range: -40~80 Celsius, Resolution:0.1 Celsius, Accuracy: ±0.5 Celsius | ||
| Measurement Technique | Moisture by FDR and EC by AC excitation | ||
| IP Ratings | IP68 | ||
| Operating Temperature | -40~85 Celsius | ||
| Sensor Rod | Stainless steel | ||
| Sensor Sealed | Epoxy resin | ||
| Installation | Surface or buried installation | ||
| Cable Length | 2 meters or Customize | ||
| Dimension | 88*71*26mm | ||
SenseCAP Soil Moisture, Temperature and pwEC Sensor
SenseCAP Soil Moisture, Temperature and pwEC Sensor
